15" Powered Subwoofer System for Fixed Installations - Black

EJW115AI-B

    DESCRIPTION

    The AtlasIED EJW115AI-B subwoofer speaker system is a high intelligibility, high efficiency speaker system that is ideally suited for use in speech and music reproduction applications for small venues like houses of worship, medium sized theaters, or schools in conjunction with the EJW2003I-B full range line array speaker system. The EJW115AI-B includes a single 15" subwoofer in an optimally designed and constructed sealed Baltic birch enclosure. This design provides even sound distribution. The EJW115AI-B includes a 500W RMS integrated class-D amplifier that includes onboard DSP. The EJW115AI-B is designed to provide power to an EJ2003I-B in a single ELIJAH line array system and includes all necessary hardware to make this connection.


    Features
    • Single 15" Subwoofer
    • Integrated 500W RMS Class D Amplifier
    • 2 Programs Onboard Digital Signal Processing
    • Finished in Heavy Duty Black Duracoat™
    • Barrier Strip Terminal for Output to Line Array and Passive Subwoofer

    SPECIFICATIONS
    Amplifier Power 1000 Watts
    Horizontal Dispersion Omni
    Frequency Response 40Hz - 200Hz
    MAX SPL 128 dB
    Height 21.6" (54.86 cm)
    Width 18.25" (46.36 cm)
    Depth 19.4" (49.28 cm)
    Weight 65 lbs (29.48 kg)
    Warranty Period 60 months from date of purchase

    SUPPORT FILES
    Owners Manual (12 pages) Owners Manual (12 pages)
