IP Addressable Dual Zone Interface with Line Level, 8Ω, 25V, 70.7V Output

Name: Discontinued Obsolete SKU
Brand: AtlasIED
SKU: ZC2PRO
Rating: 5 (5 reviews)

ZC2PRO

DESCRIPTION

The ZC2PRO Zone Controller Pro is a 2 Zone analog gateway for AtlasIED IP paging systems. This model is compatible with AtlasIED's ControlKom© and Singlewire's InformaCast© software.

The ZC2PRO provides a line level output to connect to AtlasIED commercial amplifiers and an 8Ω, 25V, 70.7V amplified output to drive small analog speaker zones. It also includes 2 GPI Inputs, 2 GPI Outputs and Microphone input for talk back applications. Power can be supplied via plug-in transformer (IPS-PSU) or by 802.3af compliant PoE network switches.

All control features of the ZC2PRO are software controlled.

SPECIFICATIONS

Rack Units	2RU (If ZCM-V2FP is Used)
Height	2.56" (65mm)
Width	8" (203mm)
Power Rating	9 Watts RMS into an 8Ω Load w/ 12VDC Input
Inputs	RJ-45 Female on PCB
Depth	10" (254mm)
Outputs	600Ω, 8Ω, 25V, or 70.7V
Power Source	IEEE 802.3af Compliant POE Network Switches / Local 12VDC - 18VDC PSU
Network Control	Multicast Enabled Networks
Sample Rate	50V @ 500mA Max
Input Minimum	1mA to Run on 50V Max
