Modular KVM Switch for LCD Console Use

MMK-KVM8

  • TAA
    DESCRIPTION
    The 8-port modular combo-free KVM switch can control attached servers and computers from local or remote consoles. This KVM switch is loaded with features including one optional IP-based remote console port (MMK-IPM), On Screen Display (OSD) Menu, Password security, Hot key Control, and Auto Scan Control. It has complete keyboard and mouse emulation for simultaneous PC boot-up process.
    With the optional IP-based remote console port you can control one or several computers locally at the server site or remotely via the Internet using a standard browser. You can securely gain BIOS level access to systems for maintenance, support, or failure recovery over the Internet. Communication is secure via SSL encryption.

    Features
    • 8 Port KVM Switch
    • Supports Combo Interface for Connecting to Computer Ports Conveniently
    • Supports One Local Console Plus One Optional Remote Console (IP)
    • Supports MS Windows®, Netware, Unix and Linux
    • Supports iMac, Power Mac, and Sun Micro Systems with USB
    • No Software Required: Easy Computer Selection Via OSD Menu, Push Buttons, and Hotkeys
    • Provide ACL (Access Control List) Security Function and Store Up to 8 Independent User Accounts

    SPECIFICATIONS
    Height 1.7" (44mm)
    Width 16.5" (420mm)
    Depth 6.7" (170mm)
    Video Resolution 1920 x 1440 (Local Console), 1280 x 1024 Remote Console
    OSD Language Support English, French, German, Spanish, Italian, Japanese, Russian, Simplified Chinese
    Warranty Period 12 months from date of purchase

    SUPPORT FILES
    MMK-KVM8 Owners Manual (24 pages) MMK-KVM8 Owners Manual (24 pages)
